About this item

•   DIMENSIONS: - 1180mm (Length) x 400mm (Width) x 1400mm. (Height).

•   SAFE AREA: - 2.2Mtr x 1.4Mtr.

  •   Horse rider equipment made from “C”  class G.I. Pipe of different NB.

        NB stands for Nominal Bore Sizes i.e. Internal Diameter of pipe in

       millimeters

  •   Make of G I Pipe will be of Tata, Jindal, Swastik, Zenith or

      Siddharth.

•   The main frame of 100NB made from “C” Class G.I. pipes welded with M.S.

       round plate of Ø250 mm & 10mm thick

•   Seat provided are made up of MS deep draw quantity of 2mm thickness with no joint with

            uniform outer edge radius 20mm.

  • The foundation used for fixing is a structure and made from center pipe of G.I. of 80 NB “B” class Welded with M.S. round plate of Ø250 mm & 10mm thick. Main pipe supported with 25 mm X 25mm M.S. angles of 3 mm thickness and 20mm x 40mm CRC square pipes of 3mm thickness.

•  The leg movement frame is of 32NB made from “B” G.I. pipe.

•  The handle frame is of 32 NB made from  “B” Class G.I. pipe.

•  The footrests are made from 25 NB “B” class G.I. pipe.

•  Pins used of Diameter   17 mm  are made up from SAE 8620 bright material.

•  The bearings used are “6203zz” permanent lubricated sealed bearing of

     reputed brand (SKF/FAG).

•   High tensile steel with galvanized nuts & bolts are used for assembly.

•   The circlips used for assembly are of A24 mm.

   •      The powder coating done with Pure Polyester powders of Ackzonoble

       or Berger with 60 to 70 micron thickness.

Only On Defective Prosuct.

All Government Taxes & GST Included.

Extra Charge On Installation.
